The product model, manufactured using both aluminum and Mild Steel materials, becomes an attractive option with its slim 3 mm slot width. Take a look at the technical details of the expanded metal mesh facade cladding product model, which is only available in thicknesses of 1.5 mm and 2 mm.
| Product Code SWD x LWD x T x SW (mm) |
Material | SWD Short Way (mm) |
LWD Long Way (mm) |
T Thickness (mm) |
SW Strand Width (mm) |
Weight (kg/m2) |
Open Area (%) |
|---|---|---|---|---|---|---|---|
| 52.00 x 115.00 x 1.50 x 24.00 | Aluminum | 52.00 | 115.00 | 1.50 | 24.00 | 10.869 | 8 |
| 52.00 x 115.00 x 2.00 x 24.00 | Aluminum | 52.00 | 115.00 | 2.00 | 24.00 | 14.492 | 8 |
