| Product Code SWD x LWD x T x SW (mm) |
Material | SWD Short Way (mm) |
LWD Long Way (mm) |
T Thickness (mm) |
SW Strand Width (mm) |
Weight (kg/m2) |
Open Area (%) |
Width x Length (mm) |
Stock Code |
|---|---|---|---|---|---|---|---|---|---|
| 2.00 x 4.00 x 0.30 x 0.30 | Aluminum | 2.00 | 4.00 | 0.30 | 0.30 | 0.233 | 72 | 1000x30.000 | ALU0204030310R |
| 2.00 x 4.00 x 0.50 x 0.60 | Aluminum | 2.00 | 4.00 | 0.50 | 0.60 | 0.800 | 41 | 1000x30.000 | ALU0204050610R |
| 2.00 x 4.00 x 0.50 x 0.60 | Aluminum | 2.00 | 4.00 | 0.50 | 0.60 | 0.800 | 41 | 1200x30.000 | ALU0204050612R |
| 2.00 x 4.00 x 0.50 x 0.45 | Mild Steel | 2.00 | 4.00 | 0.50 | 0.45 | 1.800 | 55 | 1000x15.000 | DKP0204050410R |
| 2.00 x 4.00 x 0.50 x 0.45 | Mild Steel | 2.00 | 4.00 | 0.50 | 0.45 | 1.800 | 55 | 1200x15.000 | DKP0204050412R |
| 2.00 x 4.00 x 0.50 x 0.45 | Galvanize | 2.00 | 4.00 | 0.50 | 0.45 | 1.800 | 55 | 1000x15.000 | DKP0204050410R |
| 2.00 x 4.00 x 0.40 x 0.45 | Stainless Steel | 2.00 | 4.00 | 0.40 | 0.45 | 1.400 | 55 | 1000x10.000 | PSL0204040410R |
